At Koolfog we go far beyond conventional outdoor cooling solutions. Known throughout the world as a leading innovator in misting systems and fog special effects, we apply our core high-pressure, pure water technology to a wide range of unique and customized applications and products.
Misting Poles
Koolfog Misting Poles are used in and around landscapes, decking and outdoor dining areas. Our Misting Poles are designed with an elegant yet modern style to complement most patio or landscape decor. You can find Misting Poles in commercial and community settings where there is little or no overhead structure to provide standard misting options.
MP8-03 Misting Pole
The MP8-03 Misting Pole is the latest in a line of sophisticated options for delivering high-pressure mist to hard-to-reach areas. Designed to be spread throughout a space, or grouped into artistic formations, misting poles allow for distribution of highly atomized particles of water in areas where overhead structures or other architectural elements do not allow for a standard attachment of mist line. These groupings of misting poles can consist of a handful to dozens of poles and only limited by the capacity of the Koolfog high-pressure fog pump.
Misting poles can follow a typical time of day schedule. Or – coupled with zone control and a Koolfog PLC/VFD driven pump unit – misting poles can be actuated individually or in groupings based on a variety of options including motion sensing, push buttons or temperature/humidity controls.
The MP8-03 is offered in 10 foot lengths which can be cut to varying sizes. Note: custom longer lengths are available. Nozzles are situated flush to the outside of the pole for the cleanest look possible, preventing tam- pering without the use of specialty tools. Nozzles are placed in a 360 ̊ pattern, and each of the eight nozzle ports can be capped off if desired.
| Number of Nozzles | 8 misting nozzles per pole *individual nozzle ports can be capped off |
|---|---|
| Nozzle Orientation | 360˚ orientation |
| Flow Rate | .1 – .25 GPM / .38 – .95 LPM per misting pole depending on nozzle selection |
| Material | All Stainless Steel *316 Stainless Steel Option |
| Dimensions | Height 120″ / 304.8 cm Diameter 3″ / 7.6 cm |
| Weight | 54 lbs / 24.5 kg |
| Customer selected, mirror, long grain or custom powder coat options |
Playground Misting Poles
Koolfog Playground Misting Poles are a fun alternative outdoor cooling solution and are perfect for children. Playground Misting Poles are used in playgrounds, parks, grass play areas, around pools and more. Koolfog has partnered with some of the most prominent playground equipment manufacturers to develop these safe and effective playground accents that limit heat stress while providing a ‘wow’ factor for the children.
Playground Misting Poles can be set to turn on during specific scheduled hours. Or – coupled with zone control and a Koolfog PLC/VFD driven pump unit – Playground Misting Poles can be actuated individually or in groupings based on a variety of options including motion sensing, push buttons or temperature/humidity controls.
Playground Misting Poles are offered in 10 foot lengths which can be cut to varying lengths. Note: custom longer lengths are available. Nozzles are situated flush to the outside of the pole for the cleanest look possible, preventing tampering without the use of specialty tools. Nozzles are placed in a 360 ̊ pattern, with a nozzle pointed straight up. Each of the seven nozzle ports can be capped off if desired.
MP8 Playground Misting Poles
The MP8 Playground Misting Pole is a playful interpretation for delivering high-pressure mist to hard-to-reach areas. Designed to be spread throughout a playground area, or grouped into formations, playground misting poles allow cool, fun mist features in areas where overhead structures are not present. These groupings of misting poles can consist of a handful to dozens of misting poles and only limited by the capacity of the Koolfog high-pressure fog pump.
| Number of Nozzles | 8 misting nozzles per pole *individual nozzle ports can be capped off |
|---|---|
| Nozzle Orientation | 360˚ orientation of 7 nozzles 1 nozzle on top |
| Flow Rate | .1 – .22 GPM / .38 – .83 LPM per misting pole depending on nozzle selection |
| Material | Aluminum |
| Dimensions | Height 120″ / 304.8 cm Diameter 5″ / 12.7 cm |
| Weight | 38 lbs / 17 kg |
| Customer selected, powder coat |
Misting Sculptures
Koolfog introduces a real life fusion of form and function. Our Misting Sculptures are a uniquely attractive alternative to the misting pole and will cool the environment while keeping sophisticated aesthetics intact.
Working in tandem with renowned artists, Koolfog collaborates between artist and client to produce replica or custom sculptures. Synthesizing beauty and utility, we add prominent outdoor cooling additions to any outdoor expanse.
Imaginative integration with structures perfectly designed for either utility or beauty, or both, our outdoor cooling solutions await your design.Invention, defined as “productive imagination”, is not a process that produces overnight. This two-part method begins with diligence, commitment and a dash of obsession. Only then can successful productivity emerge. Harnessing the imagination is slightly more abstract and convoluted, but often the more lively part of this process. At Koolfog, we strive to couple both concepts to professionally produce an array of sophisticated designs with practical outdoor cooling applications. Each of our cutting-edge productions took meticulous thought and carefree artistry.
